turck BL67 - Measurement Value Representation of the Outputs

D300529 0115 - BL67 I/O modules
10-27
BL67-4AI4AO-VI, voltage/current
10.1.6 Measurement value representation of the outputs
Standard representation
 16-bit-representation
dec. hex. bipolar -10 … 10 V
dec. value = 3276,7 [1/V] × voltage value [V]
100.00 % 32767 7FFF
nominal range
10.0000 V
99.99695 % 32766 7FFE 9.9997 V
…… …
50.00153 % 16384 4000 5.0002 V
…… …
0.00305 % 1 0001 0.000305 V
0.00000 % 0 0000 0.000000 V
-0.00305 % -1 FFFF -0.000305 V
…… …
-50.00000 % -16384 C000 -5.0000 V
…… …
-99.99695 % -32767 8001 -9.9997 V
-100.00 % -32768 8000 - 10.0000 V
dec. hex. unipolar 0 … 10 V
dec. value = 3276,7 [1/V] × voltage value [V]
100.00 % 32767 7FFF
nominal range
10.0000 V
99.99695 % 32766 7FFE 9.9997 V
…… …
50.00153 % 16384 4000 5.0002 V
…… …
0.00305 % 1 0001 0.000305 V
0.00000 % 0 0000 0.000000 V
-0.00305 % -1 FFFF
DIA Output value out of range
ON at FFFF to 8000
0.000000 V
…… …
-50.00000 % -16384 C000 0.000000 V
…… …
-99.99695 % -32767 8001 0.000000 V
-100.00 % -32768 8000 0.000000 V
