turck BL67 - Bl67-1 Cvi

Technology modules
D300529 0115 - BL67 I/O modules12-52
12.4 BL67-1CVI
The module BL67-1CVI is an interface to the CAN bus. It serves to connect simple digital CANopen
device (e.g. valve terminals of different manufacturers) to a BL67-System.
Figure 12-28:
z.B. PROFIBUS-DP
BL67-1CVI
Basismodul mit
Ventilversorgung über Vo
Standard CAN (DeviceNet)
Cordsets
Max. 8 Erweiterungen mit 8 Bit-A-Daten
Ventilinseln mit CANopen-Interface
Example for
connecting valve
terminals to
BL67-1CVI
