BL67-PF-24VDC, with diagnostics
Diagnostic data
This module has the following diagnostic data per channel:
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
- Overcurrent I
I
Undervoltage V
O
Undervoltage V
I
Diagnostics Meaning
4.2.3 Module parameters
none
4.2.4 Base modules/pin assignment
 BL67-B-1RSM (7/8’’)
Figure 4-3:
0
/BL67-B-1RSM-4/BL67-B-1RSM-VO
----
Table 4-3:
Diagnostics
Overcurrent I
I
Current consumption too high (> 4 A).
Undervoltage V
O
V
O
< 18 VDC
Undervoltage V
I
Sensor supply V
O
< 18 V
BL67-B-1RSM/
BL67-B-1RSM-4/
BL67-B-1RSM-VO
