turck BL67 - Module Parameters

Figure 12-46:
81
9
712102
54
63
11
v
1 = DI 3 / GND
2 = DO 3 / Venc
3 = A
4 = A
5 = B
6 = B
7 = Z
8 = Z
9 = V
SENS
10 = V
SENS
11 = V
SENS
12 = GND
D300529 0115 - BL67 I/O modules
12-85
BL67-1CNT/ENC
12.5.10 Module parameters
Pin assignment
BL67-1CNT/ENC
with
BL67-B-1M23-VI
Standard
PROFIBUS
PROFINET
Parameter
byte-
oriented
word-
oriented
Byte 0
Bit 0
Word 0
Bit 0
Byte 15
Bit 0 Input filter (A,B)
Bit 1Bit 1Bit 1
Bit 2 Bit 2 Bit 2 Signal evaluation (A,B)
Bit 3Bit 3Bit 3
Bit 4 Bit 4 Bit 4 Count direction
Bit 5 Bit 5 Bit 5 reserved
Bit 6 Bit 6 Bit 6 Invert input B
Bit 7 Bit 7 Bit 7 Invert input A
Byte 1
Bit 0 Bit 8
Byte 14
Bit 0 PullUp Z
Bit 1 Bit 9 Bit 1 Function DI3
Bit 2 Bit 10 Bit 2 Function DO3
Bit 3 Bit 11 Bit 3 Encoder signal
Bit 4 Bit 12 Bit 4 reserved
Bit 5 Bit 13 Bit 5 Synchronization with Z
Bit 6 Bit 14 Bit 6 reserved
Bit 7 Bit 15 Bit 7 Invert input Z
Byte 2
Bit 0
Word 1
Bit 0
Byte 13
Bit 0 Threshold input A, B, Z
Bit 1Bit 1Bit 1
Bit 2Bit 2Bit 2
Bit 3Bit 3Bit 3
Bit 4Bit 4Bit 4
Bit 5Bit 5Bit 5
Bit 6Bit 6Bit 6
Bit 7Bit 7Bit 7
Byte 3
Bit 0
Word 1
Bit 8
Byte 12
Bit 0 Gate function
Bit 1Bit 9Bit 1
Bit 2 Bit 10 Bit 2
Bit 3 Bit 11 Bit 3 Measurement mode
Bit 4 Bit 12 Bit 4 Counter mode
Bit 5 Bit 13 Bit 5 Invert gate
Bit 6 Bit 14 Bit 6 reserved
Bit 7 Bit 15 Bit 7 reserved
