Digital combi modules
D300529 0115 - BL67 I/O modules9-2
9.1 Overview
The digital combi modules provide optically isolated in- and outputs according to IEC 6113, type 1.
The inputs detect electrical high- and low-level val
ues through the base module connections and trans-
mit the corresponding digital value to the gateway a
nd the outputs receive output values from the
gateway via the internal module bus. The modules convert these values and transmit the correspond-
ing high or low level signals for each channel to the field level via the base modules.
The sensor supply (V
sens
) and the output supply (V
O
) are tapped from the internal voltage supply bus.
They are short circuit proof (100 mA) and supplied be the module.
Short-circuit detection is realized in the module.
WARNING!
WARNING!
LED displays
Channel statuses are indicated by LEDs. Error signals fro
m the I/O level are indicated by each module
via the "D" LED. The corresponding diagnostic information is transmitted to the gateway via diagnostic
bits.
9.1.1 Module overview
Automatic recovery of outputs
Active outputs
Deactivate the automatic recovery of outputs via the respective parameterization
Faulty safety-related switching-off
Active outputs
Switch-off digital outputs all-pole in galvanically isolated groups
ATTENTION!
High voltage when switching
-off inductive loads
Destruction of the electronic in the module
Provide an external suppressor.
Table 9-1:
Module overview
Module No. of channels Positive switching
BL67-4DI4DO-PD 4
BL67-8XSG-PD
8
BL67-8XSG-P 8
