turck BL67 - Page 221

D300529 0115 - BL67 I/O modules
7-57
BL67-8DO-0.5A-N
 BL67-B-4M12/BL67-B-4M12-P
Figure 7-74:
1
2
3
0
Figure 7-75:
4
1
3
2
5
v
1 = V
SENS
2 = Output B
3 = GND
4 = Output A
5 = PE
Figure 7-76:
4 ( ) BK
1 (+) BN
2 ( ) WH
5
BL67-B-4M12/
BL67-B-4M12-P
Pin assignment
BL67-8DO-0.5A-N
with BL67-B-4M12
Wiring diagram
B
L67-8DO-0.5A-N
with
BL67-B-4M12
