turck BL67 - Page 205

D300529 0115 - BL67 I/O modules
7-41
BL67-16DO-0.1A-P
Table 7-41:
Module parame-
ters
A default
setting
B Module firm-
ware ≥ 6
Parameter name Value Description
Threshold
Wire break detection threshold
0000 = 0 mA A
0001 = 10 mA
0010 = 20 mA
0011 = 30 mA
0100 = 40 mA
0101 = 50 mA
0110 = 60 mA
0111 = 70 mA
1000 = 80 mA
1001 = 90 mA
1010 = 100 mA
1011 = 110 mA
1100 = 120 mA
1101 = 130 mA
1110 = 140 mA
1111 = 180 mA
Value at which a wire break detection mes-
sage is generated and the output is
switched off:
0 - 180 mA
B
Older module versions:
– Module firmware ≤ version 3:
0 - 120 mA,
– Module firmware version 4:
0 - 140 mA
Overcurrent detection thresh-
old
0000 = 0 mA
0001 = 10 mA
0010 = 20 mA
0011 = 30 mA
0100 = 40 mA
0101 = 50 mA
0110 = 60 mA
0111 = 70 mA
1000 = 80 mA
1001 = 90 mA
1010 = 100 mA
1011 = 110 mA
1100 = 120 mA
A
1101 = 130 mA
1110 = 140 mA
1111 = 180 mA
Value at which a overcurrent detection
message is generated and the output is
switched off:
0 - 180 mA
B
Older module versions:
– Module firmware ≤ version 3:
0 - 120 mA,
– Module firmware version 4:
0 - 140 mA
Activate wire break monitoring no
yes
A
Activate overcurrent monitor-
ing
no A
yes
NOTE
If, in older modules, thresholds of > 120 mA are set, this setting is ignored and a threshold of
120 mA is used.
