turck BL67 - Page 191

Figure 7-36:
4
1
3
2
5
v
1 = V
SENS
2 = n.c.
3 = GND
4 = Output A
5 = PE
Figure 7-37:
3 () BU
4 ( ) BK
5
D300529 0115 - BL67 I/O modules
7-27
BL67-4DO-4A-P
 BL67-B-1M23
Figure 7-38:
0
Figure 7-39:
81
9
712102
54
63
11
v
1 = Signal 0
2 = Signal 1
3 = Signal 2
4 = Signal 3
5 = n.c.
6 = n.c.
7 = n.c.
8 = n.c.
9 = V
SENS
10 = V
SENS
11 = V
SENS
12 = GND
Pin assignment
BL67-4DO-4A-P
with BL67-B-4M12
Wiring diagram
B
L67-4DO-4A-P
with BL67-B-4M12
BL67-B-1M23
Pin assignment
BL67-4DO-4A-P
with BL67-B-1M23
