Digital output modules
D300529 0115 - BL67 I/O modules7-26
 BL67-B-2M12/BL67-B-2M12-P (paired)
Figure 7-32:
0
1
Figure 7-33:
4
1
3
2
5
v
1 = V
SENS
2 = Output B
3 = GND
4 = Output A
5 = PE
Figure 7-34:
4 (+) BK
3 () BU
2 (+) WH
5
 BL67-B-4M12
Figure 7-35:
1
2
3
0
BL67-B-2M12/
BL67-B-2M12-P
Pin assignment
BL67-4DO-4A-P
with
BL67-B-2M12/
BL67-B-2M12-P
Wiring diagram
B
L67-4DO-4A-P
with
BL67-B-2M12/
BL67-B-2M12-P
BL67-B-4M12
