Parameter name Value
0 = substitute value
A
1 = current value
00 = standard
A
01 = NE 43
10 = extended range
D300529 0115 - BL67 I/O modules
8-7
BL67-2AO-I, 0/4 … 20mA
Channel 1
Byte 3
Bit 0
Word 1
Bit 8
Byte 3
Bit 0 Output range
Bit 1 Bit 9 Bit 1 Data format
Bit 2 Bit 10 Bit 2 reserved
Bit 3 Bit 11 Bit 3 Deactivate channel
Bit 4 Bit 12 Bit 4 Output on module bus error
Bit 5 Bit 13 Bit 5
Bit 6 Bit 14 Bit 6 Data representation
Bit 7 Bit 15 Bit 7
Byte 4
Bit 0
Word 2
Bit 0
Byte 5
Bit 0 Substitute value (low byte)
Bit 1 Bit 1 Bit 1
Bit 2 Bit 2 Bit 2
Bit 3 Bit 3 Bit 3
Bit 4 Bit 4 Bit 4
Bit 5 Bit 5 Bit 5
Bit 6 Bit 6 Bit 6
Bit 7 Bit 7 Bit 7
Byte 5
Bit 0 Bit 8
Byte 4
Bit 0 Substitute value (high byte)
Bit 1 Bit 9 Bit 1
Bit 2 Bit 10 Bit 2
Bit 3 Bit 11 Bit 3
Bit 4 Bit 12 Bit 4
Bit 5 Bit 13 Bit 5
Bit 6 Bit 14 Bit 6
Bit 7 Bit 15 Bit 7
Table 8-5:
Module parame-
te
rs
A default
setting
Output range 0 = 0 … 20 mA A
1 = 4 … 20 mA
Data format 0 = 15 bit + sign
A
1 = 12 bit (left-justified)
Deactivate channel 0 = no
A
1 = yes
Output on module bus error
Data representation
Substitute value Substitute value = "0"
A
The substitute value will be transmitted if the
respective parameters of the gateway have been
set to "output substitute value" if the communica-
tion between module and gateway is disturbed.
Standard
PROFIBU
S
PROFINET
Parameter
byte-
oriented
word-
oriented
