Analog input modules
D3
00529 0115 - BL67 I/O modules6-48
Table 6-33:
Module parame-
ters
A default
setting
B valid for
firmware
version
≥
15
Parameter name Value
Measurement range 0 = 0 … 10 V/0 … 20 mA
A
1 = -10 … +10 V/4 … 20 mA
Data format 0 = 15 bit + sign
A
1 = 12 bit (left-justified)
Deactivate diagnostics 0 =no
A
1 = yes
Deactivate channel 0 =no
A
1 = yes
Operation mode 0 = voltage
A
1 = current
Data representation 00 = standard
01 = NE 43
B
10 = extended range
B
Concerning the "number representation", please observe the tables for measurement value
representation on the following pages.
