Technology modules
D300529 0115 - BL67 I/O modules12-54
Table 12-1:
Technical data
Designation BL67-1CVI
Number of channels 1
Nominal voltage from supply terminal 24 VDC
Load voltage V
O
24 VDC
Voltage range 18 to 30 VDC
Nominal current consumption from 5 VDC (mod-
ule bus) I
MB
≤ 30 mA
Nominal current from supply terminal (field) I
L
< 100 mA (if load current = 0)
Power loss of the module, typical < 1.5 W
CAN
U
RS1
(active) min. 500 mV
U
RS1
(inactive) max. 200 mV
U
GLRS
(common mode) -7 to 12 V
Power supply (valve electronic)
Output current
High level
A
(nominal value) 0.5 A
High-level I
AMAX
0.6 A (according to IEC 6 1131-2)
Switch-on resistance R
ON
190 mΩ
Simultaneity factor 100 %
Switch-off characteristic K
A
I
OUT
> 1.5 A < 4 ms
1.0 A < I
OUT
≤ 1.5 A < 10 s
0.6 A < I
OUT
≤ 1.0 A min. 10 s/max. 60 s
Power supply (valves)
Output current
High level
A
(nominal value) 1 A
High-level I
AMAX
1.2 A (according to IEC 6 1131-2)
Switch-on resistance R
ON
95 mΩ
Simultaneity factor 100 %
Switch-off characteristic K
A
I
OUT
> 3 A < 4 ms
2 A < I
OUT
≤ 3 A < 10 s
1.2 A < I
OUT
≤ 2 A min. 10 s/max. 60 s
