Analog input modules
D300529 0115 - BL67 I/O modules6-28
Table 6-17:
Module parame-
ters
A default
setting
Parameter name Value
Mains suppression 0 = 50 Hz A
1 = 60 Hz
Data format 0 = 15 bit + sign
A
1 = 12 bit (left-justified)
Deactivate diagnostics 0 =no
A
1 = yes
Deactivate channel 0 =no
A
1 = yes
RTD type 0000 = Pt100, -200 … 850 °C
A
0001 = Pt100, -200 … 150 °C
0010 = Ni100, -60 … 250 °C
0011 = Ni100, -60 … 150 °C
0100 = Pt200, -200 … 850 °C
0101 = Pt200, -200 … 150 °C
0110 = Pt500, -200 … 850 °C
0111 = Pt500, -200 … 150 °C
1000 = Pt1000, -200 … 850 °C
1001 = Pt1000, -200 … 150 °C
1010 = Ni1000, -60 … 250 °C
1011 = Ni1000, -60 … 150 °C
1100 = resistance, 0 … 100 Ω
1101 = resistance, 0 … 200 Ω
1110 = resistance, 0 … 400 Ω
1111 = resistance, 0 … 1000 Ω
Measurement mode 0 = 2 wire
A
1 = 3 wire
