Analog input modules
D300529 0115 - BL67 I/O modules6-38
Table 6-26:
Module parame-
ters
A default
setting
Parameter name Value
Mains suppression 0 = 50 Hz A
1 = 60 Hz
Data format 0 = 15 bit + sign
A
1 = 12 bit (left-justified)
Deactivate diagnostics 0 =no
A
1 = yes
Deactivate channel 0 =no
A
1 = yes
Thermocouple type 0000 = Type K, -270 … 1370 °C
A
0001 = Type B, +100 … 1820 °C
0010 = Type E, -270 … 1000 °C
0011 = Type J, -210 … 1200 °C
0100 = Type N, -270 … 1300 °C
0101 = Type R, -50 … 1760 °C
0110 = Type S, -50 … 1540 °C
0111 = Type T, -270 … 400 °C
1000 = +/-50 mV
1001 = +/-100 mV
1010 = +/-500 mV
1011 = +/-1000 mV
