BL67-4DO-2A-P
 BL67-B-1M23
Figure 7-25:
0
Figure 7-26:
81
9
712102
54
63
11
v
1 = Signal 0
2 = Signal 1
3 = Signal 2
4 = Signal 3
5 = n.c.
6 = n.c.
7 = n.c.
8 = n.c.
9 = V
SENS
10 = V
SENS
11 = V
SENS
12 = GND
BL67-B-1M23
Pin assignment
BL67-4DO-2A-P
with BL67-B-1M23
