Digital output modules
D300529 0115 - BL67 I/O modules7-34
 BL67-B-4M12/BL67-B-4M12-P
Figure 7-45:
1
2
3
0
Figure 7-46:
4
1
3
2
5
v
1 = V
SENS
2 = Output B
3 = GND
4 = Output A
5 = PE
Figure 7-47:
4 (+) BK
3 () BU
2 (+) WH
5
 BL67-B-1M23
Figure 7-48:
0
BL67-B-4M12/
BL67-B-4M12-P
Pin assignment
BL67-8DO-0.5A-P
with BL67-B-4M12
Wiring diagram
BL67-8DO-0.5A-P
with
BL67-B-4M12
BL67-B-1M23
