turck BL67 - Page 213

Figure 7-62:
4
1
3
2
5
v
1 = V
SENS
2 = Output B
3 = GND
4 = Output A
5 = PE
Figure 7-63:
4 ( ) BK
1 (+) BN
2 ( ) WH
5
D300529 0115 - BL67 I/O modules
7-49
BL67-4DO-2A-N
 BL67-B-4M12
Figure 7-64:
1
2
3
0
Figure 7-65:
4
1
3
2
5
v
1 = V
SENS
2 = n.c.
3 = GND
4 = Output A
5 = PE
Figure 7-66:
1 (+) BN
4 ( ) BK
5
Pin assignment
BL67-4DO-2A-N
with BL67-B-2M12/
BL67-B-2M12-P
Wiring diagram
B
L67-4DO-2A-N
with BL67-B-2M12/
BL67-B-2M12-P
BL67-B-4M12
Pin assignment
BL67-4DO-2A-N
with BL67-B-4M12
Wiring diagram
BL67-4DO-2A-N
with BL67-B-4M12
