Analog output modules
D300529 0115 - BL67 I/O modules8-10
 12-bit-representation (left-justified)
The representation of the 12 bit values corresponds to that of the 16 bit values. Only bits 0 to 3 are set
to "0".
dec. hex. 4 … 20 mA
dec. value = 1728 [1/mA] × (current value [mA] - 4 mA)
32767 7FFF 22.962 mA
32752 7FF0 22.954 mA
32512 7F00 22.8148 mA
32511 7EFF
out of range
22.8142 mA
32496 7EF0 22.8056 mA
27664 6C10 20.0093 mA
27649 6C01 20.0006 mA
27648 6C00
nominal range
20 mA
16 0010 4.009259 mA
1 0001 4.000578 mA
00000 4.0000 mA
-1 FFFF
out of range
3.99942 mA
-16 FFF0 3.99075 mA
-6912 E500 0.0000 mA
-6913 E4FF 0.0000 mA
-27648 9400 0.0000 mA
-27649 93FF 0.0000 mA
-27664 93F0 0.0000 mA
-32512 8100 0.0000 mA
-32513 80FF 0.0000 mA
-32752 80F0 0.0000 mA
-32768 8000 0.0000 mA
