turck BL67 - Page 251

D300529 0115 - BL67 I/O modules
8-29
BL67-4AO-V, -10/0 … +10 VDC
Extended range - value representation
 16-bit-representation
dec. hex. bipolar -10 … 10 V
dec. value = 2764,8 [1/V] × voltage value [V]
118.515 % 32767 7FFF
DIA Output value out of
range ON at 7F00 to 7FFF
11.851 V
118.461 % 32752 7FF0 11.846 V
117.593 % 32512 7F00 11.7593 V
117.589 % 32511 7EFF
out of range
11.7589 V
117.535 % 32496 7EF0 11.7535 V
100.058% 27664 6C10 10.0058 V
≥ 100,004 % 27649 6C01 10.0004 V
100.000 % 27648 6C00
nominal range
10 V
0.05787 % 16 0010 5.787 mV
0.003617 % 1 0001 361,7 μV
0.000 % 0 0000 0 V
-0.00362 % -1 FFFF -361,7 μV
-0.05787 % -16 FFF0 - 5,787 mV
-25.000 % -6912 E500 -2.5 V
-100.000 % -27648 9400 -10 V
≤ -100,004 % -27649 93FF
out of range
-10.0004 V
-100.058 % -27664 93F0 -10.0058 V
-117.593 % -32512 8100 -11.7593 V
-117.596 % -32513 80FF
DIA Output value out of
range ON at 08FF to 8000
11.7596 V
-118.461 % -32752 80F0 -11.846 V
-118.519 % -32768 8000 -11.852 V
