Digital combi modules
D300529 0115 - BL67 I/O modules9-32
Switch-on resistance R
on
max. 190 mΩ
Resistive, inductive and lamp loads can be connected.
– Load impedance, resistive R
LO
48 Ω
– Lamp load R
LL
3 W
Switching frequency
– resistive load 200 Hz
– inductive load 2 Hz
–lamp load 20 Hz
Isolation voltage
U
TMB
(module bus/field) max. 2500 VDC
U
FE
(field/functional earth) max. 1000 VDC
Short-circuit proof yes, according to EN 61 131-2
NOTE
The parallel switching of outputs is possible with the synchronous switching of the channels.
In this case, the maximum output current can be increased up to 2 A, depending on the num-
ber of the parallel switched outputs.
