BL67-4AI4AO-VI, voltage/current
Value representation process automation (NE 43)
 16-bit-representation
 12-bit-representation (left-justified)
The representation of the 12 bit values corresponds to that of the 16 bit values. Only bits 0 to 3 are set
to "0".
dec. hex. bipolar -10 … 10 V
dec. value = 1000 [1/V] × voltage value [V]
327.67 % 32767 7FFF
DIA Overflow/underflow ON
at 2AF9 to 7FFF
11.000 V
110, 01 % 11001 2AF9 11.000 V
110.00 % 11000 2AF8
DIA Output value out of range
ON at 2905 to 7FFF
11.000 V
105.01 % 10501 2905 10.501 V
105.00 % 10500 2904
overdrive
10.500 V
100.01 % 10001 2711 10.001 V
100.000 % 10000 2710
nominal range
10.000 V
40.00 % 4000 0FA0 4.000 V
0.01 % 1 0001 0.001 V
0.000 % 0 0000 0 V
-0.01 % -1 FFFF -0.001 V
-40.00 % -4000 F060 -4.000 V
-100.00 % -10000 D8F0 -10.000 V
≤ -100,01 % -10001 D8EF
underdrive
-10.001 V
-105.00 % -10500 D6FC -10.500 V
-105.01 % -10501 D6FB
DIA Output value out of range
ON at D6FB to 8000
-10.501 V
-110.00 % -11000 D508 -11.000 V
-110.01 % -11001 D507
DIA Overflow/underflow ON
at D507 to 8000
-11.000 V
-327.68 % -32768 8000 -11.000 V
dec. hex. unipolar 0 … 10 V
dec. value = 1000 [1/V] × voltage value [V]
655.35 % 65535 FFFF
DIA Overflow/underflow ON
at 2AF9 to FFFF
11.000 V
110, 01 % 11001 2AF9 11.000 V
110.00 % 11000 2AF8
DIA Output value out of range
ON at 2905 to FFFF
11.000 V
105.01 % 10501 2905 10.501 V
105.00 % 10500 2904
overdrive
10.500 V
100.01 % 10001 2711 10.001 V
100.000 % 10000 2710
nominal range
10.000 V
40.00 % 4000 0FA0 4.000 V
20.00 % 2000 07D0 2.000 V
0.01 % 1 0001 0.001 V
0.000 % 0 0000 0 V
