BL67-2AI2AO-VI, voltage/current
Input 1
Byte 4
Bit 0
Word 2
Bit 0
Byte 5
Bit 0 Operation mode
Bit 1 Bit 1 Bit 1
Bit 2 Bit 2 Bit 2
Bit 3 Bit 3 Bit 3
Bit 4 Bit 4 Bit 4 Data format
Bit 5 Bit 5 Bit 5 Deactivate diagnostics
Bit 6 Bit 6 Bit 6 reserved
Bit 7 Bit 7 Bit 7
Output 1
Byte 5
Bit 0 Bit 8
Byte 4
Bit 0 Operation mode
Bit 1 Bit 9 Bit 1
Bit 2 Bit 10 Bit 2
Bit 3 Bit 11 Bit 3
Bit 4 Bit 12 Bit 4 Data format
Bit 5 Bit 13 Bit 5 Deactivate diagnostics
Bit 6 Bit 14 Bit 6 Output on module bus error
Bit 7 Bit 15 Bit 7
Byte 6
Bit 0
Word 3
Bit 0
Byte 6
Bit 0 Substitute value (low byte)
Bit 1 Bit 1 Bit 1
Bit 2 Bit 2 Bit 2
Bit 3 Bit 3 Bit 3
Bit 4 Bit 4 Bit 4
Bit 5 Bit 5 Bit 5
Bit 6 Bit 6 Bit 6
Bit 7 Bit 7 Bit 7
Byte 7
Bit 0 Bit 8
Byte 8
Bit 0 Substitute value (high byte)
Bit 1 Bit 9 Bit 1
Bit 2 Bit 10 Bit 2
Bit 3 Bit 11 Bit 3
Bit 4 Bit 12 Bit 4
Bit 5 Bit 13 Bit 5
Bit 6 Bit 14 Bit 6
Bit 7 Bit 15 Bit 7
Concerning the "number representation", please observe the tables for measurement value
representation on the following pages.
