Technology modules
D300529 0115 - BL67 I/O modules12-78
– High-level I
AMAX
0.6 A (according to IEC 6 1131-2)
Switch-off characteristic K
A
–I
OUT
> 1.5 A < 0.8 s
– 1,0 A < I
OUT
> 1,5 A < 3 s
–0,6 A < I
OUT
> 1,0 A min. 3 s/max. 10 s
Simultaneity factor 100 %
Switching frequency
with resistive load 100 Hz
with inductive load 2 Hz
with lamp load ≤ 10 Hz
Lamp load R
LL
≤ 10 W
Short-circuit proof yes
Isolation voltages
U
TMB
(module bus/IOs) 1000 VDC
U
field
(field/IOs) 0 VDC
U
FE
(module bus or field/FE) 100 VDC
Measurement ranges
Frequency measurement 250 kHz
single max. 250 kHz
double max. 250 kHz
fourfold max. 125 kHz
Period duration measurement 400 ns to 858,9 s
Count modes
signal evaluation A, B, Z – pulse and direction
– encoder, single
– encoder, double
– encoder, quadruple
counter mode – continuous count
– periodical count (if Synchronization with Z is
parameterized as periodical)
synchronization single-action
periodical
Count limits
upper count limit 0×8000 0000 to 0×7FFF FFFF
Can be freely chosen, whereas the upper count
limit must always be higher than the lower count
limit.
lower count limit
