Designation Access to the interfaces
D300529 0115 - BL67 I/O modules
12-93
BL67-1CNT/ENC
… reserved
REG_MEASURE_TIME 60 Time out for period duration mea-
surement/gate time for frequency
measurement
100
Table 12-14:
Access to the reg-
isters
RD = read
WR = write
No. Process
output
Storage
in module
Process
input
Parame-
ter
Diagnos-
tic mes-
sage
REG_CNT_POS 0 RD
REG_MAGIC_NO 1 RD
REG_HW_VER 2 RD
REG_SW_VER 3 RD
REG_SF 4 RD
REG_IF_VER 5 RD
REG_DIAG1 16 RD RD
REG_PARA1 20 WR non
volatile
RD WR
REG_PARA4 23 WR non
volatile
RD WR
REG_COUNTER_VALUE 32 WR RD
REG_LOWER_LIMIT 36 WR non
volatile
RD
REG_UPPER_LIMIT 40 WR non
volatile
RD
REG_LOAD_VALUE 44 WR non
volatile
RD
REG_MEASURED_VALUE 48 RD
REG_SCALE_MUL 52 WR non
volatile
RD
REG_SCALE_DIV 56 WR non
volatile
RD
REG_MEASURE_TIME 60 WR non
volatile
RD
Table 12-13:
Register
description
Designation No. Description Default (HEX)
