turck BL67 - Page 491

D300529 0115 - BL67 I/O modules
15-31
Cross reference list parameters
Overcurrent Overcurrent detection threshold
0000 = 0 mA
0001 = 10 mA
0010 = 20 mA
0011 = 30 mA
0100 = 40 mA
0101 = 50 mA
0110 = 60 mA
0111 = 70 mA
1000 = 80 mA
1001 = 90 mA
1010 = 100 mA
1011 = 110 mA
1100 = 120 mA
1101 = 130 mA
1110 = 140 mA
1111 = 180 mA
Output on overcurrent Output behavior at overcurrent
0 = automatic recovery
1 = controlled recovery
Analog modules
Range Measurement range
0 = 0 … 10V/0 … 20 mA
1 = -10 … 10V/4 … 20 mA
Operation mode
–BL67-4AI-V/I
0 = voltage
1 = current
Operation mode
–BL67-4AO-V
–BL67-2AI2AO-V/I
–BL67-4AI4AO-V/I
0000 = voltage, -10 … 10 V standard
0001 = voltage, 0 … 10 V standard
0010 = voltage, -10 … 10 V NE43
0011 = voltage, 0 … 10 V NE43
0100 = voltage, -10 … 10 V ext. range
0101 = voltage, 0 … 10 V ext. range
1000 = current 0 … 20 mA standard
1001 = current 4 … 20 mA standard
1010 = current 0 … 20 mA NE43
1011 = current 4 … 20 mA NE43
1100 = current 0 … 20 mA ext. range
1101 = current 4 … 20 mA ext. range
Diagnosis Deactivate diagnostics
0 = activate
1 = deactivate
0 = no
1 = yes
Table 15-5:
Cross reference list
parameters
Parameters OLD Parameters NEW
