Digital input modules
D300529 0115 - BL67 I/O modules5-44
 BL67-B-4M12/BL67-B-4M12-P (paired)
Figure 5-63:
1
2
3
0
Figure 5-64:
4
1
3
2
5
v
1 = V
SENS
2 = Input B
3 = GND
4 = Input A
5 = PE
Figure 5-65:
3 () BU
4 ( ) BK
1 (+) BN
2 ( ) WH
5
5
1 (+) BN
3 () BU
2 ( ) WH
4 ( ) BK
BL67-B-4M12/
BL67-B-4M12-P
Pin assignment
B
L67-8DI-N with
BL67-B-4M12/
BL67-B-4M12-P
Wiring diagram
B
L67-8DI-N with
BL67-B-4M12/
BL67-B-4M12-P
