Vacon 100 flow Applications Manual

Table 43: Digital input settings
Index Parameter Default ID Description
P3.5.1.46 Pump 5 Interlock DigIN Slot0.1 430
OPEN = Not active
CLOSED = Active
P3.5.1.47 Pump 6 Interlock DigIN Slot0.1 486
OPEN = Not active
CLOSED = Active
P3.5.1.48 Pump 7 Interlock DigIN Slot0.1 487
OPEN = Not active
CLOSED = Active
P3.5.1.49 Pump 8 Interlock DigIN Slot0.1 488
OPEN = Not active
CLOSED = Active
P3.5.1.52 Reset kWh Trip Counter DigIN Slot0.1 1053
P3.5.1.53 Parameter Set 1/2 Selection DigIN Slot0.1 496
OPEN = Parameter Set 1
CLOSED = Parameter Set 2
P3.5.1.54 Multi-Setpoint Selection 0 DigIN Slot0.1 15576
P3.5.1.55 Multi-Setpoint Selection 1 DigIN Slot0.1 15577
P3.5.1.56 Multi-Setpoint Selection 2 DigIN Slot0.1 15578
P3.5.1.57 Multi-Setpoint Selection 3 DigIN Slot0.1 15579
P3.5.1.58 Flow Switch DigIN Slot0.2 15590
P3.5.1.59 AHF Over Temperature DigIN Slot0.1 15513
* = The selection of the application with parameter P1.2 Application gives the default value.
See the default values in 12.1 The default values of parameters in the different applications.
NOTE!
Your option board and board setup gives the number of available analogue inputs.
The standard I/O board has 2 analogue inputs.
VACON · 140 PARAMETERS MENU
5
LOCAL CONTACTS: HTTP://DRIVES.DANFOSS.COM/DANFOSS-DRIVES/LOCAL-CONTACTS/

Vacon 100 flow Specifications

General

Protection class	IP20
Communication interface	RS-485
Operating temperature	-10°C to +50°C
Storage temperature	-40°C to +70°C
Ambient temperature	-10°C to +40°C
Control method	Sensorless vector control
Communication protocols	CANopen
Approvals	CE, UL
I/O	2 analog inputs
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Frequency range	0 Hz to 400 Hz
Humidity	5% to 95%, non-condensing
Voltage range	208-240 V
