Make sure that the cable is properly attached to the mast or cross arm
before starting the installation. Otherwise, it may slip and fall down during the
installation procedure.
CAUTION!
To avoid strain on the connector, make sure you connect the cable properly.
Too much strain may cause the cable to fall
o, damage the cable or connector, or make
the cable or connector susceptible to water leakage.
CAUTION!
The recommended minimum bending radius for the cable is 70 mm (2.76 in).
1. Insert the cable in the cable tightening tool.
Vaisala recommends that you use the cable tightening tool. The ribbed part of the tool
oers a better grip of the cable when tightening the connector. You do not need to
remove the tool when the connector is tightened.
1 Cable tightening tool
2 Cable
2. Align the male and female connectors.
Chapter 6 – Wind Sensor or Weather Transmitter Installation
53
