WXT536 WXT535 WXT534 WXT533 WXT532 WXT531
Parameter Description
P
Pressure
T
Temperature
U
Humidity
R
Rain
W
Wind
The transmitters power up with 5 … 32 VDC and output serial data with a selectable
c
ommunica
tion protocol:
SDI-12
ASCII automatic and polled
NMEA 0183 with query option
The WXT530 series has four serial interface options:
RS-232
RS-485
RS-422
SDI-12
The transmitter is equipped with the following connectors:
8-pin M12 connector for installation
4-pin M8 connector for service use
The transmitter housing is IP65/66 rated.
The following table shows dierent options available for the product family.
Table 2 Available Options
Available options WXT53
6
WXT53
5
WXT53
4
WXT53
3
WXT53
2
WXT53
1
Service Pack 2: Windows-based Vaisala
Configuration Tool software with USB
servic
e cable (1.4 m)
USB RS-232/RS-485 cable (1.4 m)
WXT530 Series User Guide M211840EN-D
12
