8.1.6.2 Common Sensor Settings (aIU)
Update Interval [I]
T
he upda
te interval in seconds. This parameter defines the measurement interval for analog
inputs:
• P
t1000
• Solar radiation
• Aux rain
The range: 0.5 … 3600.
8.1.6.3 Aux Input Averaging Time [A]
The Aux Input averaging time in seconds. This parameter defines the averaging time for
ultrasonic le
vel sensor and solar radiation measurement. Pt1000 and the tipping bucket are
not aected by this setting.
Make sure the averaging time is smaller than the update interval [I]. The smallest value
0.25 s means single measurement. A longer averaging time can decrease noise. A shorter
averaging times gives a slightly smaller current consumption.
8.1.6.4 Parameter Selection [R]
[R]
defines
the active measurements.
Table 31 aIU Setting Fields [R]
Normal message 1 st bit (most left) Tr pt1000 temperature
2 nd bit Ra Aux rain amount
3 rd bit Sl ultrasonic level sensor
4 th bit Sr solar radiation
5 th bit Rt pt1000 resistance
6 th bit
7 th bit Analog output mode
8 th bit
& delimiter
Composite message 9 th bit Tr pt1000 temperature
10 th bit Ra Aux rain amount
11 th bit Sl Ultrasonic level sensor
12 th bit Sr solar radiation
13 th bit Rt pt1000 resistance
14 th bit 0
15 th bit 0
WXT530 Series User Guide M211840EN-D
