Setting Default value Definition
Aux. rain gain 0.2 mm Comes from the rain sensor tipping bucket size. It
means pulses / user rain unit (f
or example, mm). If the
aux. sensor has 5 pulses per mm of rain, and the user
sets the gain to 0.2, the rain value reported by the
transmitter is in mm.
Aux. rain counter limit Used only when L = based on limit is selected. Resets
the rain c
ounter when it reaches this value. The same
unit as the gain G has.
• All measurement messages enabled
• Upda
te interval 60 s
• Solar radiation and ultrasonic level sensor averaging time 3 s
• Solar radiation gain 100 000
• Ultrasonic level sensor range 5 V
• Ultrasonic level sensor gain 1
• Aux temperature average time 1 s
• Aux rain counter reset: manual
• Aux rain gain 0.2 (for 0.2 mm per tip)
WXT530 Series settings:
0IU,R=11111000&11111000,I=60,A=3.0
0IB,G=100000.0
0IS,M=1,G=1.0
0IP,A=1.0
0IA,M=M,G=0.2
8.1.6.1
Enabling and Disabling Analog Input
If the analog input option is selected for WXT536, all analog inputs are enabled by default.
You can enable and disable analog input with the
aIU,R= command.
For example, PT1000 temperature enabled, all other disabled:
aIU,R=1000000010000000
You mus
t reset the transmitter to apply the new setting. When analog input is in use, the
serial port does not work. The service connector functions.
More Information
‣
Enabling or Disabling Analog Output (page 145)
Chapter 8 – Sensor and Data Message Settings
139
