7. Retrieving Data Messages
Each communication protocol has its own section for data message commands.
Type commands in CAPITAL letters.
The parameter order in messages is as follows:
Wind (M1): Dn Dm Dx Sn Sm S
x
PTU (M2): Ta Tp Ua Pa
Rain (M3): Rc Rd Ri Hc Hd Hi Rp Hp
Supv (M5): Th Vh Vs Vr Id
Comp (M): Wind PTU Rain Supv (parameters in above order)
The order of the parameters is fixed, but you can exclude any parameter from the list
when configuring the transmitter.
7.1 General Commands
With general commands you can reset the transmitter.
If error messaging is disabled, the general commands given in ASCII and NMEA formats
do not work.
7
.1.1 Reset (aXZ)
This command performs software reset on the device.
Command f
ormat in ASCII and NMEA 0183:
aXZ<cr><lf>
C
ommand f
ormat in SDI-12:
aXZ!
a
Device address
XZ
Reset command
Chapter 7 – Retrieving Data Messages
77
