2.3.1 USB Cables

Figure 9 USB Cable

• USB RS-

232/RS-485 cable with 8-pin M12 threaded connector (1.4 m)

• USB service cable with 4-pin M8 threaded connector (1.4 m)

The service cable, while connected between the service port and PC, forces the service port

to RS-232 / 19200, 8, N, 1.

You need a driver for the USB cable.

WXT530 Series User Guide M211840EN-D
