4.4.1

Mounting WXT530 on Vertical Pole Mast without

Mounting Kit

1. Remove the screw cover and insert the transmitter to the pole mast.

2. Align the transmitter so that the arrow points to North.

3. Tighten the ﬁxing

screw and replace the screw cover.

4.4.2 Mounting WXT530 on Vertical Pole Mast with Mounting

Kit

2.5‑mm and 5‑mm Allen ke

When mounting a transmitter on a pole mast, you can use an optional mounting kit to ease

mounting.

Chapter 4 – Installation
