Applicable
Standar
d
Description Level tested
Performance
1)
CISPR 22 Conducted emissions DC 150 Hz ... 30 MHz Class B
IEC 61000-4-2 Electrostatic discharge 8 kV con / 15 kV air B
IEC 61000-4-3
RF
field
immunity
2)
10 V/m and 3 V/m A
IEC 61000-4-4 Electric fast transient 3 kV B
IEC 61000-4-5 Surge 2 kV B
IEC 61000-4-6 Conducted RF immunity 3 V A
IEC 60945 Radiated emissions 150 kHz ... 2 GHz All locations including
Bridge and Open
Deck
IEC 60945 Conducted emissions 10 kHz ... 30 MHz All locations including
Bridge and Open
Deck
IEC 60945 Electrostatic discharge 8 kV con / 15 kV air B
IEC 60945 RF field immunity 10 V/m and 3 V/m A
IEC 60945 Electric fast transient 3 kV B
IEC 60945 Surge 2 kV B
IEC 60945 Conducted RF immunity 3 kV A
IEC 60945 Conducted low frequency
in
t
erference immunity
10 %Vnom B
IEC 60945 Extreme power supply
varia
tion
-10 % +30 % A
IEC 60945 Power supply failure 3 times 60 s B
1) A = Normal performance
B = Tempor
ary degradation (self-recoverable)
C = Temporary degradation (operator intervention needed)
D = Not recoverable
2) Within frequency range 600 ... 700 MHz immunity for PTU is 8 V/m.
11.4 Mechanical Specifications
Table 47 WXT530 Series Mechanical Specifications
Property Description/Value
Weight
WXT534, WXT535, WXT536 0.7 kg (1.54 lbs)
WXT531, WXT532, WXT533 0.5 kg (1.1 lbs)
WXT530 Series User Guide M211840EN-D
162
