Parameter Description
Wind Direction Oset
aSU,g=4<cr><lf>
WD minimum
aSU,h=0<cr><lf>
WD ma
ximum
aSU,j=22<cr><lf>
WD error indication
aSU,k=2<cr><lf>
The output o in mA is o=i* gain + oset.
o is clamped between min and max. If wind
measurement fails, the output value is err.
8.1.7.2 Analog Output Scaling
You can specify the transfer function between measured values and output analog values.
You can selec
t the analog output gain and oset used in the transfer function.
The factory default settings for the dierent
analog output modes are displayed in the
following table.
Table 32 Analog Output Scaling
Parameter 4 … 20 mA
option (max 60
m
/s)
0 … 20 mA
option (max 60
m/s)
Command example (4 … 20 mA)
Aout1, Wind Speed Gain 0.266667 mA /
m/
s
0.333333 mA /
m/s
aSU,a=0.266667<cr><lf>
Aout1, Wind Speed Oset 4 mA 0 mA
aSU,b=4<cr><lf>
A
out1, Wind Speed Minimum 0 mA 0 mA
aSU,c=0<cr><lf>
Aout1, Wind Speed Maximum 22 mA 22 mA
aSU,d=22<cr><lf>
Aout1, Wind Speed Error
Indication
2 mA 22 mA
aSU,e=2<cr><lf>
A
out2, Wind Direction Gain 0.044444 mA / ° 0.055556 mA / °
aSU,f=0.044444<cr><lf>
Aout2, Wind Direction Oset 4 mA 0 mA
aSU,g=4<cr><lf>
Aout2, Wind Direction Minimum 0 mA 0 mA
aSU,h=0<cr><lf>
Aout2, Wind Direction Maximum 22 mA 22 mA
aSU,j=22<cr><lf>
Aout2, Wind Direction Error
Indication
2 mA 22 mA
aSU,k=2<cr><lf>
You can configure
output scaling or transfer function settings by changing the custom gain
and oset. The basic measurement units are m/s and degrees. The physical output unit is A.
The following formula shows the impact of gain and oset values on the produced output:
o = y0 + k×s
WXT530 Series User Guide M211840EN-D
144
