Vaisala WXT530 Series User Manual

o
Produced analog output (A)
s
Measured wind speed or direction (in m/s or °)
k
Selected gain value
y0
Selected oset
value
8.1.7.3 Analog Output Signal for Wind Speed Channel
The analog interfaces setup, default configuration:
Current output 4 ... 20 mA,
oset 4 mA
4 mA = 0 m/
s
20 mA = 60 m/s (0,266667 mA/m/s)
Error indication sets output to 2 mA.
The analog interfaces setup,
configuration 2:
Curr
ent output 0 … 20 mA, oset 0 mA
0 mA = 0 m/
s 20 mA = 60 m/s (0.333333 mA/m/s)
Error indication sets output to 22 mA.
8.1.7.4 Analog Output Signal for Wind Direction Channel
Analog in
terfaces setup default configuration:
Current output 4 ... 20 mA, oset 4 mA
4 mA = 0 degr
ee 20 mA = 360 degr
ee (0,044444 mA/°)
Error indication sets output to 2 mA
Analog interfaces setup, configuration 2:
C
urrent output degree 0 ... 20 mA, oset 0 mA
0 uA = 0 degree
20 mA = 360 degr
ee (0,055556 mA/°)
Error indication sets output to 22 mA
8.1.7.5 Enabling or Disabling Analog Output
When changing the analog output setting, the setting is applied after the transmitter reset.
W
hen analog output is in use
, the serial port does not work but the service connector does.
The 12th bit from left determines if analog output is enabled:
• Analog output enabled at the factory: 0XF,f=1111111111110000
• Analog output disabled at the factory: 0XF,f=1111111111100000
You can enable or disable analog output with the aWU,R= command.
• To enable analog output: Change bit 7 to 1. 0WU,R=1111111111111100
• To disable analog output: Change bit 7 to 0. 0WU,R=1111110111111100
Chapter 8 – Sensor and Data Message Settings
145
