Figure 20 Mounting WXT531 on Vertical Pole Mast

Handle with care. Any impact on the instrument or sensor array may cause

damage and lead to inc

orrect measurements.

CAUTION!

1. Remove the adapter sleeve from the mounting kit.

ead the sensor cable through the mounting kit, and connect the cable to the bottom

part of the sensor.

WXT530 Series User Guide M211840EN-D
