Username Vanderbilt CCIC1410 and CFMC1315 cameras only.
Enter a login username for the camera which will be added to the command
string below when the Update Cmd. String button is clicked.
Password Vanderbilt CCIC1410 and CFMC1315 cameras only.
Enter a login password for the camera which will be added to the command
string below when the Update Cmd. String button is clicked.
Command
String
Enter the command string to be sent to the HTTP server on the camera in
order to obtain images. This string should include the user name and
password for the camera. Consult the camera documentation for the specific
string required for the camera type selected.
The default command string for a Vanderbilt CCIC1410 or CFMC1315
camera with no password is "/cgi-bin/stilljpeg".
Pre-event
images
Enter the number of pre-event images to record (0–16). Default is 8.
Pre-event
interval
Enter the time interval, in seconds, between pre-event images (1–10). Default
is 1 second.
Post-event
images
Enter the number of post-event images to record (0–16). Default is 8.
Post-event
interval
Enter the time interval, in seconds, between post-event images, in seconds
(1–10). Default is 1 second.
Configuring Verification Zones
To create a verification zone
1. Go to Configuration > Advanced > Verification > Verification zones.
A list of any existing verification zones is displayed.
2. Click the Add button.
3. Enter a Description for the zone.
4. Select an Audio expander from the drop down list.
5. Select a Video from the drop down list.
6. Click the Save button.
7. Assign this verification zone to a physical zone on the SPC system. (See Editing a zone on
page270.)
See also
Editing a zone on page270
SPC4xxx/5xxx/6xxx – Installation & Configuration Manual Engineer programming via the browser
© Vanderbilt 2018 293 A6V10276959-d
11.2018
