– Reach in through the lowest air grill to unscrew bolts -arrow-
(3 bolts) of air guide.
– Unscrew bolt -arrow- next to headlights on left and right.
– Push radiator module in direction of engine and release clips
-arrows- of air guide on top of radiator and remove.
– Release locking pins -B- of both upper radiator mountings
-A- by pressing in direction of -arrow- and pulling out upwards.
– Remove the two radiator mountings at top -A-.
– Take radiator module out upwards.
Installing:
• Specified torques ⇒ page 164 .
– Install radiator module from above.
– Fit radiator mountings on top at front end and bolt them on.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
168 Rep. gr.19 - Cooling
