– Turn crankshaft from below using counterhold - T10172- in
engine direction of rotation to TDC no. 1 cylinder marking.
Cams -A- of cylinder 1 must face each other.
– Unscrew bolt for camshaft adjuster approx. 1 turn at outlet end,
using an open-ended spanner to counterhold on flat side of
camshaft.
– Unscrew bolt for camshaft adjuster approx. 1 turn at inlet end,
using an open-ended spanner to counterhold on flat side of
camshaft.
Touareg 2010 ➤ , Touareg 2015 ➤
6-cylinder direct-injection engine (3.6 l engine, 4V) - Edition 12.2019
1. Chain drive 67
