SHB WL34 * 2.0 8-27
Hydraulic system 8
Designation of hydraulic components
8.15 Designation of hydraulic components
Designation
AActuators
A4 Lock cylinder
A20 Lifting cylinder
A49 Master brake cylinder
A68 Lift cylinder with counterbalance valve
A69 Tilt cylinder with counterbalance valve
A71 Tilt cylinder
A100 Steering cylinder
M Drive Motors
M05 Variable displacement motor A6VM80
PPumps
P1 Variable displacement pump A4VG56
P10 Variable displacement pump A4VG40
P37 Hydraulic gear pump 19 ccm
P44 Variable displacement pump A4VG56DA
P62 Variable displacement pump A4VG40DA
S Signal sensor
S1 Steering orbitrol OSPF 200 OLS
V Valves
V5 Priority valve OLS 80
V6 Non-return valve 5 bar
V7 Non-return valve 1 bar
V15 Control valve HDM19/4
V22 Control valve HDM19/3
V30 2/2 directional valve, electric (lock)
V37 Control valve HDS 15/1
V72 Hydraulically switchable lock (3/2 way)
V75 Vibration damping valve
V80 6/2 directional valve
V123 Drive valve TH7 M-Drive
