SHB WL34 * 2.0 11-9
Cabin 11
Heating
18.Open the fastening clip.
19.Lead the cable through opening 12.
20.Remove screws 13.
21.Open the fastening clip 14 and remove the cable from the casing.
22.Remove screws 15.
23.Remove two screws on both sides 16.
24.Take out the blower.
Install in the reverse order.
Fig. 294
12
Fig. 295
13
Fig. 296
15
14
Fig. 297
16
