Prepare the sample management system for operation
July 29, 2013, 715003794 Rev. B 111
• A “Compression Check Failed” error message appears.
• A “Missing Restrictor” alarm appears during a diagnostic procedure.
• You change the seal pack or needle.
• You rebuild the seal pack.
Before you adjust the seal pack, purge the sample management system to
ensure the syringe is empty of air. Air in the system can cause the Alarm Seal
Geometry or Alarm Missing Restrictor dialog boxes to (erroneously) appear.
To adjust the seal pack:
1. In the Main screen, press the Diag screen key.
2. In the Diagnostics screen, press the Adjust Seals screen key.
Result: The adjustment procedure begins. When the procedure
completes, the results are shown (see “Adjust the seals” on page 226).
Load carousels
The following table lists the carousels and their color codes.
To load the carousels:
1. Open the carousel door.
Tip: The message the “Door is Open” appears.
2. Press the Next screen key (or select the desired carousel screen key) to
position the carousel turntable for loading the appropriate carousel.
3. Load the carousel into the sample compartment.
4. Repeat step 2 and step 3 until all carousels are loaded.
Carousel codes and colors:
Code Color Vial numbers
ABlue 1 to 24
B Yellow 25 to 48
CRed 49 to 72
D Green 73 to 96
E White 97 to 120
