3 Prepare the e2695 Separations Module for Operation
88 July 29, 2013, 715003794 Rev. B
Enter values in parameter fields
To enter parameter values:
1. Use the screen keys or the Menu/Status key to display the appropriate
screen.
2. Use the arrow keys to select the parameter field you want to change.
3. When a diamond appears after the field name, do as follows:
a. Press Enter to display a drop-down list.
b. Use the arrow keys to select the value you want, then press Enter.
4. When you need to enter data into a field, do as follows:
• Use the numeric keys to enter a numeric value, then press Enter.
• Use the screen keys to enter alphabetic data, then press Enter. See
“Enter an alphanumeric string” on page 89 for more information.
5. To select a check box, do as follows:
Toggles the display between the menu mode and the
status/control mode.
Immediately stops the flow of solvent and terminates a
current function (sample processing, priming, purging,
and so on). Pressing this key also activates the Run
Stopped output switch.
Enters the corresponding numeral into a current field,
selects the corresponding gradient curve (0 = curve 10),
positions the cursor to the corresponding entry in a list
(0 = tenth item).
Enters a decimal point, selects gradient curve 11, or serves
as a separator for vial ranges. For example, to enter 2
through 5 in a vial field, press 2.5. Also positions the
cursor to the last entry in a list.
Keypad functions: (Continued)
Key Function
To Next Page
