Operating overview
July 29, 2013, 715003794 Rev. B 87
Keypad functions:
Key Function
Moves the cursor one field to the left.
Moves the cursor one field to the right.
Moves the cursor to the field above a current field.
Moves the cursor to the field below a current field.
Moves the cursor to the left most field in a current row.
Press twice to move the cursor to the first field in the
screen.
Moves the cursor to the right most field in a current row.
Press twice to move the cursor to the last field in the
screen.
Increases the display contrast.
Decreases the display contrast.
Displays a context-sensitive Help screen. Press twice to
display a general Help screen. To close the Help screen,
press Exit or Clear.
Closes an open menu or dialog box and reestablishes the
previous screen.
Clears the contents of a current field, or enters INIT or
OFF in selected fields.
Stores the contents of a current field and advances the
cursor to the next field in the screen.
