Maintain the sample management system
July 29, 2013, 715003794 Rev. B 201
Remove side panel of separations module
Some maintenance procedures, such as sample loop and needle and seal-pack
replacement, require that you remove the side panel of the separations
module to access internal components.
Note: This section only applies if you are using the column heater or column
heater/cooler option and need to remove that unit to access the side panel on
the separations module. If you are not using this option, consult the
appropriate maintenance item for side panel removal instructions.
Required materials
Screwdriver, T-20 TORX
To access and remove the side panel:
1. Power-off the separations module.
e2695 Sample management system assemblies/components:
Assembly/component Function
Syringe Draws sample from the sample vial into the
sample loop.
Sample carousels and
carousel carrier
Five, color-coded carousels. Each carousel holds
up to 24 sample vials for a total capacity of 120
sample vials.
Injector motor Controls injector needle movement.
Sample loop transducer Senses backpressure developed by resistance to
solvent flow in the sample loop.
Sample loop Holds up to one sample-loop volume (standard
100 µL) of sample.
Needle tee Holds the injector needle and provides the
connector for sample loop.
Needle (see the figure
“Remove the injector
assembly:” on page 212)
Perforates the sample vial caps, draws sample,
and injects the sample into the flow path.
Seal pack (see the figure
“Remove the injector
assembly:” on page 212)
Contains high-pressure seals and the needle
wash system.
