Waters Alliance e2695 - Create and Edit a Sample Set

6 Create Methods, Sample Sets, and Sample Templates
174 July 29, 2013, 715003794 Rev. B
Create and edit a sample set
A sample set is a table of instructions that the separations module uses to
perform an automated run in a standalone mode. During a run, the
separations module performs the function in each row of the table
sequentially.
To create and edit a sample set:
1. On the Main screen, click the Develop Methods screen key.
2. On the Methods screen, click the New screen key.
2487 and 486 Detector actions:
Action Function Value range
Set wavelength Sets the wavelength of the detector. 2487: 190 to 700 in
1 nm increments
486: 190 to 600 in
1 nm increments
Set filter Sets the time constant of the filter in
the detector.
2487: 0.1 to 99.0 in
0.1 sec increments
486: 0.1 to 5.0 in
0.1 sec increments
Set AU full
scale
Sets the absorbance units full scale
to adjust the sensitivity of the
detector.
2487: 0.0001 to
4.0000 in 0.0001
AU increments
486: 0.001 to 2.000
in 0.001 AU
increments
Set chart mark Sends a chart mark signal to the
output terminals.
2487 and 486: (No
values)
Set chart
polarity
Sets the polarity of the analog
output.
2487 and 486: +, –
Auto zero Performs an autozero on the detector. 2487 and 486:
(No values)
Set lamp Turns the lamp on and off. 2487 and 486: On,
Off
