3 Prepare the e2695 Separations Module for Operation
98 July 29, 2013, 715003794 Rev. B
Configure the operating mode
Use the System field in the Configuration screen to select one of nine
operating modes:
• No Interaction – For standalone operation.
• System Controller – For standalone operation when controlling Waters
detectors over the IEEE-488 interface.
• Controlled by Empower – For Empower software operation when the
software controls the HPLC system via Ethernet or the IEEE-488
interface.
• Controlled by MassLynx – For MassLynx software control via the
IEEE-488 cable interface.
• Operate Gradient by Event In – Use when an autosampler (external to
the separations module) initiates a chromatographic run via contact
closure.
Compressible
Volume
• 25-µL syringe
• 250-µL syringe
• 2500-µL syringe
Sets the maximum
displacement volume
to produce the
compression
pressure.
1 to 15 µL
5 to 30 µL
5 to 100 µL
15 µL
20 µL
50 µL
Decay Time Sets the amount of
time that the system
is kept at the
compression
pressure.
0.0 to 999.99
min
1.0 min
Maximum Delta
Decay
Sets the maximum
difference in
pressure between
the beginning and
the end of the decay
time.
0 to 5000 psi < 345 kPa
(< 3.45 bar,
< 50 psi)
Compression check parameters: (Continued)
Parameter Description Range
Typical
value
