Waters Alliance e2695 - Page 97

Configure the separations module
July 29, 2013, 715003794 Rev. B 97
Sample report (Continued):
Compression check parameters
The separations module provides a compression check to test for leaks in the
sample loop, seal pack, and valves (V1, V2, and V3).
You enter the parameter values that determine whether the separations
module passes or fails a compression check in the Compression Check dialog
box.
To specify the compression check parameters:
1. Press the More screen key in the Configuration screen, and then press
the Comp Check screen key.
2. Enter an appropriate value in each field, and then press OK.
Tip: The following table lists the ranges and typical values for each
parameter. Waters recommends you use the typical values for each
parameter to best characterize the system.
Compression check parameters:
Parameter Description Range
Typical
value
Compression
Pressure
Sets the target
pressure for the
compression check.
206.8 to
2068.4 kPa
(2 to 20.7
bar, 30 to
300 psi)
689.5 kPa
(6.9 bar,
100 psi)
(2410 Polarity: [+]
Table: (min) Detector Action Param
1. INIT 2487 (1) Set wavelength 254
2. INIT 2487 (1) Set filter
3. INIT 486 (1) Set AU full scale 1.234
4. INIT 486 (1) Set chart polarity [+]
5. INIT 486 (1) Auto zero
OVERVIEW (min) Action
1. INIT 2487(1) 254 nm
2. INIT 2487(1) filter 1.0
3. INIT 2487(1) 1.234 AUFS
4. INIT 2487(1) chart polarity pos
5. INIT 2487(1) auto zero
6. INIT 1.000 mL/min 100.0%A 0.0%B 0.0%C 0.0%D c6
7. INIT Set Switch 1
->Sample injected at 03/17/08 02:26:42pm( 10.0 uL from vial 1 )
